Daewoo MATIZ Service Manual page 1036

9H – 6 SEATS
Installation Procedure
1. Install the head restraint into the guide sleeves. Press
down in order to engage the stop pin.
D109B531
FRONT SEATBACK
Removal Procedure
1. Disconnect the negative battery.
2. Remove the front seat assembly. Refer to "Front
Seats" in this section.
3. Remove the recliner knob from the front seat.
D Remove the screw (1).
D Remove the recliner knob (2).
D109B532
4. Remove the recliner cover from the front seat.
D Remove the screws (1).
D Remove the recliner cover (2).
D109B533
5. Remove the recliner from the front seat.
D Remove the bolts on the seat cushion (1).
D Remove the seatback cover hog rings.
D Remove the seatback cover (2).
D Remove the bolts on the seatback (3).
D109B534
DAEWOO M-150 BL2
