3B – 10 MANUAL TRANSAXLE DRIVE AXLE
6. Remove the drive axle shaft boot.
D104B704
Assembly Procedure
1. Install in the reverse order of removal.
2. Fill the joint housing with recommended grease when
installing.
Capacity
Notice: Always use the recommended grease. If not,
joint and boot can be damaged.
Important: Always use new clamps.
Inspection Procedure
1. Inspect the operation of joint.
D104B705
2. Inspect for a leaking boot through the clamp side.
OUTER JOINT (WHEEL SIDE)
Disassembly Procedure
1. Remove the drive axle. Refer to "Drive Axle Assem-
bly" in this section.
2. Remove the clamps on the joint boot.
D Remove the boot clamps (1,2).
D104B706
3. Degrease the joint assembly.
4. Remove the joint assembly.
D Widen the circlip (1).
D Remove the joint assembly while widening the cir-
clip (2).
D104B707
90–100 g (3.2–3.5 ounces)
DAEWOO M-150 BL2
