Manual Window Regulator Handle; Tailgate Strut - Daewoo MATIZ Service Manual

9P – 28 DOORS
Installation Procedure
1. Install the door opening weatherstrip to match the
marking.
2. Install the rocker panel trim and the lower B–pillar
panel trim.
D109C631
MANUAL WINDOW REGULATOR
HANDLE
Removal Procedure
1. Remove the window regulator handle.
D Using a cloth, pull out the clip (1).
D Remove the window regulator handle (2).
D109E543
Installation Procedure
1. Install the window regulator handle with the clip.
D109C632

TAILGATE STRUT

Removal Procedure
1. Open the tailgate and suitably support it.
2. Remove the tailgate strut assembly.
D Remove the end fitting nut from the ball studs (rear
body) (1).
D Removethe end fitting nut from the ball studs (tail-
gate) (2).
D19C634A
DAEWOO M-150 BL2
