DTC P1385 – Rough Road Sensor Circuit Fault (NON ABS)
Step
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
1
Was the check performed?
1. Turn the ignition ON, with engine OFF.
2. Install a scan tool to the Data Link Connector
(DLC).
3. Review and record the scan tool Failure Records
data.
2
4. Operate the vehicle within Failure Records
conditions as noted.
5. Using the scan tool, monitor specific Diagnostic
Trouble Code (DTC) info for DTC P1382.
Does the scan tool indicate that DTC P1382 failed?
1. Check for the following conditions and repair as
needed:
2. VR sensor seal missing or damaged.
3
3. VR sensor mounting flanges cracked, missing, or
incorrectly installed.
Is the repair complete?
1. Turn the ignition OFF.
2. Disconnect the VR sensor electrical connector.
3. Turn the ignition ON, with the engine OFF.
4
4. Observe the VR sensor value displayed on the
scan tool.
Is the VR sensor value near the specified value?
1. Jumper the 5 volt reference circuit, terminal 1 and
the VR sensor signal circuit, terminal 2 together at
the VR sensor harness connector.
5
2. Observe the VR sensor value displayed on the
scan tool.
Is the VR sensor value near the specified value?
1. Turn the ignition OFF.
2. Disconnect the Engine Control Module (ECM) and
check the sensor ground circuit for high
resistance, an open between the ECM and the
6
VR sensor, or for a poor connection at the
terminal 85 of the ECM and repair as needed.
Is the repair complete?
Check the 5 volt reference circuit for high resistance,
an open between the ECM and the VR sensor, or a
poor connection at the terminal 85 of the ECM and
7
repair as needed.
Is the repair complete?
1 Turn the ignition OFF.
2. Disconnect the ECM and check the VR sensor
signal circuit for high resistance, an open, a low
8
voltage, or a short to the sensor ground circuit
and repair as needed.
Is the repair complete?
DAEWOO M-150 BL2
Action
ENGINE CONTROLS 1F – 175
Value(s) Yes
–
Go to Step 2
–
Go to Step 4
–
Go to Step 14
0V Go to Step 5
4.95V Go to Step 6
–
Go to Step 14
–
Go to Step 14
–
Go to Step 14
No
Go to
"On-Board
Diagnostic
System Check"
Go to Step 3
Go to
"Diagnostic
Aids"
Go to Step 12
Go to Step 7
Go to Step 10
Go to Step 8
Go to Step 9
