Daewoo MATIZ Service Manual page 985

DAEWOO M-150 BL2
INSTRUMENTATION/DRIVER INFORMATION 9E – 11
GLOVE BOX
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the hinge pins at the base of the glove box.
D109B509
2. Remove the glove box from the instrument panel.
D109B510
Installation Procedure
1. Install the glove box to the instrument panel with the
hinge pins.
D109B509
INSTRUMENT CLUSTER
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the instrument cluster trim panel from the in-
strument panel. Refer to "Instrument Cluster Trim
Panel" in this section.
3. Remove the instrument cluster assembly from the in-
strument panel.
D Remove the screws (1).
D Disconnect the electrical connector and the
speedometer cable (2).
D19B514A D Remove the instrument cluster (3).
