9F – 10 AUDIO SYSTEMS
ROOF ANTENNA
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the interior courtesy lamp. Refer to Section
9B, Lighting Systems.
3. Remove the roof antenna.
D Remove the screw from the vehicle inside (1).
D Remove the roof antenna (2).
D109D561
Installation Procedure
1. Install the roof antenna with the screw.
Tighten
Tighten the roof antenna retaining screw to 3 NSm (27
lb-in).
3 NSm
a. Roof antenna retaining screw.
2. Install the interior courtesy lamp. Refer to Section 9B,
Lighting Systems.
3. Connect the negative battery cable.
D19D562A
