Fax Extension - Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference

MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features

Fax Extension

Fax Extension
At a Glance
Users Affected
Reports Affected
Modes
Telephones
System Programming
Maximums
Fax machines using the Fax
Extension feature
Message-Waiting
Receivers programmed for
each fax extension
Factory Setting
Fax Message Threshold
Description
The Fax Extension feature provides special treatment for single-line ports (ports
on 012 (T/R) or 016 (T/R) modules and ports programmed for tip/ring operation on
412 LS-ID-ETR and 016 ETR modules) when used with a facsimile machine or
fax modem. This special treatment disables those features normally provided to
single-line ports but not suitable for fax machines, such as:
Distinctive ringing
Call Waiting
Transfer, Hold, and Conference
In addition to the above, the Fax Extension feature also provides the ability to
notify certain extensions when a fax is received by turning on the Message LED.
Extensions so enabled are called fax message-waiting receivers.
Telephone users, operators
Direct Group Calling Information, Extension Directory,
Extension Information, Label Information
All
Tip/ring for fax extension. All for message-waiting receiver.
Identify fax extension jacks:
AuxEquip Fax
Assign fax message-waiting receivers:
AuxEquip Fax
Specify length of time before system sends fax message-
waiting indication:
AuxEquip Fax
16
4
10 seconds (range 0–30)
Extension
Msg Waiting
Threshold
Issue 1
April 1999
322
