Personal Lines - Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference

MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features

Personal Lines

Personal Lines
At a Glance
Users Affected
Reports Affected
Modes
Telephones
System Programming
Maximums
Factory Settings
Assigned Personal Lines
Description
A personal line, also called a direct facility termination (DFT), is an outside
line/trunk assigned to a button on one or more telephones or to another type of
extension, such as a data communications device. A personal line can provide
either the shared or exclusive use of a specific line/trunk. In Hybrid/PBX mode, a
personal line allows users to receive outside calls without operator involvement.
When a personal line is assigned to more than one extension, a principal user of
the personal line can be assigned through system programming. Assigning an
extension as the principal user has the following effects:
If Remote Call Forwarding is enabled for the extension, only the principal
user can forward personal line calls to an outside telephone number.
Unless the personal line is set to No Ring, calls received on the personal
line follow the principal user's Individual or Group Coverage patterns.
To select a personal line to make or receive outside calls, The user presses the
associated personal line button on a multiline telephone; a dial-out code is not
needed. When the line is in use, the green LED is on at all multiline telephones
that share the personal line.
Telephone users, operators, data users
Extension Information
All
All except QCC
Assign or remove personal lines:
Extensions
Assign or remove principal user of a personal line:
LinesTrunks
64 extensions for each personal line
1 extension as principal user
3 simultaneous users for each personal line
Analog DLCs: Lines 1–32
MLX DLCs: Lines 1–18
Multiline telephones: Lines 1–8 (Key mode)
LinesTrunks
More
PrncipalUsr
Issue 1
April 1999
484
