MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features
Direct Station Selector
Table 12. Results of Pressing DSS Button while Active on a Call: QCC Position
Extension Type
Individual or calling
group
Pool dial-out code or
ARS code
Paging group
Park zone
Line/trunk number,
LDN, unassigned
extension numbers,
dial 0 calls
The red LEDs for each DSS button are used to determine whether a user is on a
call (off hook), has no call active (on hook), or is using Do Not Disturb. The LED
indication (on) is the same for off hook and Do Not Disturb; however, in Release
2.0 and later systems, the DSS button can be inspected to determine whether the
user is on a call or has activated Do Not Disturb.
For a calling group extension on a DSS button, the red LED indicates the status of
the queue. In Release 5.0 and later systems, the DSS button flashes if the
number of calls waiting in the queue is greater than or equal to Threshold 1 but
fewer than Threshold 3. The LED lights steadily if the number of waiting calls is
greater than or equal to Threshold 3. If three thresholds are needed, an inside
Auto Dial button should be used to monitor queue status.
For a pool dial-out code on a DSS button, the red LED indicates line/trunk
availability.
In Release 6.1 and later systems pressing a DSS button for a non-local dial plan
extension will cause the appropriate routing pattern and route to be chosen. The
Result
The caller is put on hold, the transfer is initiated, and the extension
is dialed automatically. If extended call completion is programmed
with the Manual option, the operator must press the Release
button or hang up to complete the transfer. If extended call
completion is programmed with the Automatic option, the transfer
is completed automatically.
The caller is put on hold, the transfer is initiated, and the pool
dial-out or ARS code is dialed automatically. The operator can then
dial the telephone number. Transfer completion is always manual
whether extended call completion is programmed as manual or
automatic.
The caller is put on hold, a Call button is automatically selected,
and the paging group extension number is automatically dialed.
The call transfer process is not initiated automatically because
calls cannot be transferred to a paging group.
The Park feature is activated, and the call is put on hold in the
selected park zone to allow Pickup from any extension in the
system.
Ignored; no effect.
Issue 1
April 1999
246
