Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference page 892

MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
General Feature Use and Telephone Programming
Telephone Programming
Table D-8. Programming TransTalk MDC 9000 and MDW Telephones
Step
1 Label the button to be
programmed.
NOTE:
Skip this step if the feature
will not be programmed onto
a button.
2 Begin programming.
3 Select the feature or setting.
4 End programming.
Action
Remove the clear label cover from the telephone
by pulling up on the tab that extends from the top of
the cover.
Write the feature name on the card next to the
button to be programmed.
Replace the cover.
Press the imprinted Feat button.
Dial 00.
Press the button you labeled.
NOTE:
If the feature does not get programmed onto
a button, press any line button. This does not
affect the button in any way.
Dial the programming code.
The feature is programmed.
Press the imprinted Feat button.
Dial 00.
Issue 1
April 1999
D-34
