Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference page 327

MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features
Directories
MLX-20L Telephones
While a Personal Directory on an MLX-20L telephone is being programmed, you
cannot receive calls (the caller hears a busy signal), but you still can hear the
telephone ringing. In Release 1.0 systems, ringing is normal. In Release 1.1 and
later systems, ringing occurs at 20-second intervals.
To use the System or Extension Directory feature on an MLX-20L telephone,
press the Menu button, select Directory from the display, and select either type
of directory from the display. Next, choose a range of letters from which to begin
the search. The display shows the first seven listings that begin with the first letter
in the range.
To scroll through the listings, select either Next Page to display the next seven
entries or Prev Page to display the previous seven entries. To display the
telephone number associated with an individual listing, select Show Number from
the display—Show Number is highlighted—and press the button next to the
listing. To exit the Show Number function, select Show Number again—the
highlight is removed from Show Number. To dial a number for a listing shown on
the display, press the button next to the listing.
To use the Personal Directory on an MLX-20L telephone, press the Home button;
a QCC operator selects Directory from the Home screen. If listings have been
programmed to appear on the Home screen, the first eight listings (six listings for
a QCC operator) are shown. To see the second eight listings (six listings for a
QCC operator), select Next Page. To select listings by using a range of letters,
select Next Page from the Home display twice . Use the same procedure to
search for listings as you do for System and Extension Directories. To dial a
number for a listing shown on the display, press the button next to the listing.
NOTES:
The number for a marked Personal Directory listing is displayed when
you choose Show Number. A marked Personal Directory listing is
specifically designated during programming to suppress the telephone
number from the display when the number is dialed from the display.
Marked System Speed Dial entries (entries that do not display) are not
affected by the Second Dial Tone setting. If a marked System Speed
Dial entry uses star codes and the central office does not immediately
supply dial tone when a star code is entered, the appropriate number of
pauses (1.5 seconds each) must be programmed after each star code in
the entry.
Issue 1
April 1999
267
