Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference page 369

Feature/Description
UDP Displays (continued)
Call arriving on an extension programmed for
extension or ANI calling number only
Same call arriving on an extension
programmed for label, extension, or ANI (both)
UDP over tie lines
Caller ID line assigned to a calling group with a
non-local member 2000 over PRI private
network
MLX ETR
Page 1, Line 1: Page 1, Line 1:
OUTSIDE Ext OUTSIDE Ext
5010 5010
Page 2, Line 1: Page 2, Line 1:
Trk8125 4010 Trk8125 4010
(No timeout)
Page 1, Line 1: Page 1, Line 1:
OPERATR Ext OPERATR Ext
5010 5010
Page 2, Line 1: Page 2, Line 1:
Trk8125 4010 Trk8125 4010
(No timeout)
Page 1, Line 1: Page 1, Line 1:
TIE-TRK TIE-TRK
Page 2, Line 1: Page 2, Line 1:
Trk801 Trk801
(No timeout)
Page 1, Line 1: Page 1, Line 1:
PRI-UDP 732- PRI-UDP 732-
957-9604 957-9604
Page 2, Line 1: Page 2, Line 1:
Trk3810 2000 Trk3810 2000
(No timeout)
Sample Displays
MLS
No display
change; Pre- or
post-select:
PRI-UDP or
NAME
No display
change; Pre- or
post-select:
PRI-UDP or
NAME
No display
change; Pre- or
post-select:
TIE-UDP
No display
change; Pre- or
post-select:
Calling party
number or name
Analog Multiline
No display
change; Pre- or
post-select:
PRI-UDP or
NAME
No display
change; Pre- or
post-select:
PRI-UDP or
NAME
No display
change; Pre- or
post-select:
TIE-UDP
No display
change; Pre- or
post-select:
Calling party
number or name
