Microphone Disable - Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference

MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features

Microphone Disable

Microphone Disable
At a Glance
Users Affected
Reports Affected
Modes
Telephones
System Programming
Factory Setting
Description
Microphone Disable can be assigned through system programming to any MLX
telephone, except a Queued Call Console (QCC), to limit the use of the
speakerphone. When the feature is assigned, the microphone does not function,
but the speaker functions normally. A user can listen to calls or announcements
over the speakerphone but must use the handset to respond.
For some features, such as Auto Dial, Last Number Dial, or Saved Number Dial,
the system automatically selects a line and activates the speakerphone. When
one of these features is used on a telephone with Microphone Disable assigned,
the system selects the line and activates the speaker, but the microphone is
muted automatically; the red LED next to the Mute button lights. To be heard, lift
the handset. The Mute and Speaker LEDs go off.
Also, when group pages or voice-announced transfers are received on a
telephone with Microphone Disable assigned, you can hear the announcement
over the speakerphone, but the microphone is muted automatically. Lift the
handset to speak to an inside caller who is either transferring a call or calling you
through an SA Voice or ICOM Voice button. Microphone Disable is appropriate
when speakerphones pick up too much background noise, or when they are
needed by only some employees.
Considerations and Constraints
The LED next to the Mute button goes on whenever the speakerphone is
activated. Pressing the Mute button does not turn off the LED or deactivate
Microphone Disable.
Telephone users, DLC operators
Extension Directory
All
All MLX (except QCC)
Enable or disable individual MLX telephone microphones:
Extensions
Enabled
More
Mic Disable
Issue 1
April 1999
444
