Lucent Technologies MERLIN LEGEND Release 7.0 Feature Reference page 802

MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features
Uniform Dial Plan Features
Maximums
UDP Routing Patterns
UDP Routes
UDP FRL
UDP Digit Absorption
UDP Added Digits
Number of digits in
non-local dial plan
extension number range
Factory Settings
Display Preference
Switch Identifier
UDP FRL
UDP Absorbed Digits
UDP Added Digits
NOTES:
Specify voice, data, or both for an identified UDP route (use
for routes with pools of PRI or T1 facilities):
Tables
Dial route no.
Enter
When SMDR is set to record both incoming and outgoing
calls, specify how private networked trunk calls should be
recorded (for Release 6.1 and later systems):
LinesTrunks
no.
20 (range 1–20)
4 (range 1–4)
6 (range 0–6)
11 (range 0–11)
20 (any digits 0–9)
4 (2- and 3-digit numbers also supported)
Calling number
No value; facility not networked
3
0
0
This topic only summarizes information about private networks. Detailed
information is included in the Network Reference.
DEFINITY ECS and DEFINITY ProLogix Solutions features and
operations are beyond the scope of this guide. This book discusses the
network from the MERLIN LEGEND Communications Systems'
perspective.
When a network consists of more than two systems, a coordinating
system manager should act as a coordinator for all changes to private-
network systems' dial plans, non-local dial plans, ARS routing, UDP
routing, and remote access. Otherwise, the two system managers
should plan together and agree upon any changes that are made
subsequently.
UDP Routing
Enter Data
Exit Exit Exit
More
UDP
Select logging option
Enter
Issue 1
April 1999
Dial pattern no.
Enter
Select capability
Exit
Dial line/trunk
SMDR
742
