MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features
Direct Station Selector
The meaning of the red LED associated with each group member is shown in
Table 14.
Table 14. LED Meanings for Supervisor Operation without Message Status Active
Extension
LED Status Status
Off 0
o
On 2
Slow Flashing 1
NOTE:
The LEDs next to DSS buttons for all other types of extensions are always
off and have no meaning.
Extension Status Operation (Hotel Configuration)
When Extension Status is in Hotel configuration, the Extension Status feature is
assigned to and removed from individual DLCs through system programming (see
''Extension Status'' on page 317
always active, unless the Message Status button has been pressed to use the
Auto Dial or DSS buttons to see the message-waiting status for each extension.
Pressing a DSS button while in Hotel Extension Status operation has the same
effect as for normal call-handling operations.
When not in Message Status operation, the red LED next to each DSS button for
a room extension is used to monitor room availability, and the DSS button is used
to restrict the extensions when the rooms are not occupied.
In Release 6.1 and later systems Extension Status Operation is available only for
local extensions.
The meaning of the red LED next to the DSS button for each room is shown in
Table 15.
Meaning
The extension is signed out from the group, and the
member is unavailable to take calls.
The extension is signed into the group, and calls can be
sent to the member.
Used for CMS only; the extension is in the after-call work
state, and the group member is not available to take calls.
for details). Hotel Extension Status operation is
Issue 1
April 1999
249
