MERLIN LEGEND Communications System Release 7.0
Feature Reference 555-670-110
Features
Direct Station Selector
DSS LED associated with the non-local dial plan are not updated for any feature
including switchhook operation, therefore the extinguished appearance for a non-
local dial plan extension does not indicate the true state of the extension. Do Not
Disturb information is not conveyed because the LED is extinguished. Using the
Inspect button only provides the extension number for a non-local dial plan
extension. If the facilities are busy that are needed to make the call to the non-
local dial plan extension associated with the pressed DSS button, the call is
queued. The called MERLIN LEGEND blocks calls to the non-local dial plan
Paging groups, and if an attempt is made to use the console to activate a feature
associated with a remote extension, the feature generally will not work.
Also in Release 6.1 and later systems, a called switch may not act on an external
call from a DSS button on another MERLIN LEGEND System. For example, a
page may not be connected at the called extension.
Table 13 shows the meanings of the red LEDs for DSS buttons for local
extensions while the operator position is in normal operation and message status
is not active.
Table 13. ED Meanings for Normal Call-Handling Operation
LED Status Extension Type
Off Individual
o
Line/Trunk number The line/trunk is not in use. The LED is always off for
Pool dial-out code
Calling group
Paging group
Operator Park
Zone
ARS, Remote
access, LDN
On Individual
Line/trunk number
Pool dial-out code
Table 13 does not apply to non-local extensions.
Meaning
The person is not on the telephone and is not using
Do Not Disturb.
a DID trunk or a Switch 56 trunk on a DLC.
At least one line/trunk is available for making an
outside call.
The calling group queue is below the programmed
threshold (in Release 5.0 and later systems, below
Threshold 1).
The group is available for making a group
announcement.
A call is not parked on this park zone code.
Not applicable; the red LED is always off.
The person is on the telephone or has activated the
Do Not Disturb feature.
The line/trunk is in use. No indication appears for a
busy DID trunk or Switch 56 trunk on a DLC.
No lines/trunks are available in this pool for outside
calls.
Issue 1
April 1999
247
