Mobile Groups

How a Port's Primary Mobile Group Changes (move_from_def)

If move_from_def is enabled....
Default Group 1
Primary Group 3
Helpful Hints:
• Reduces broadcasts to the default group.
• Best used when only one device is
attached to each port.
Page 19-10
Default/Primary
Mobile Group 1
Device on port matches poli-
cy in another mobile group
(3). Group 3 becomes prima-
ry group.
Port assigned to default
group 1 or another group
through or
If move_from_def is disabled....
Default/Pri
Mobile Group 1
Secondary
Mobile Group 3
Device on port matches poli-
cy in another mobile group
(3). Group 1 remains primary
group. Group 3 is now a
"secondary" group for this
port.
Why disable move_from_def?
• When multiple devices are attached to
the switch port, the port must support
multiple traffic in the default group as
well as traffic in the secondary mobile
groups.
