Displaying Link Status
Peer Call Address
The number to which this call is connected. Zero (0) means the number is not available.
Connection Time
The value of "sysUpTime" (the time of day) when the call was connected. Zero (0) means
the call is not currently connected.
Call State
The current call state. The possible entries are
(meaning the call is in the process of connecting),
connected),
nected), and
Call Origination
The call origin. Possible entries are
(meaning the call was incoming).
Displaying Status for a Specific WAN Link
To view detailed status information on a specific WAN Link, you must enter its Link Index
with the command.
For example, to examine Link 1 (an ISDN link), you would enter following command:
A screen similar to the following displays:
The fields on this screen have the following meanings:
Connect Time
Accumulated connect time to the peer since system start-up. This is the total connect time,
i.e., the connect time for outgoing calls plus the time for incoming calls.
Success Calls
The number of completed calls to the Peer ID related to this WAN Link.
Failed Calls
The number of failed call attempts, or any reason, to the Peer ID related to this WAN Link
since system start-up.
Accepted Calls
The number of calls from the Peer ID related to this WAN Link accepted since system start-
up.
Page 31-16
(meaning the call is active),
(meaning that the state is unknown).
(meaning the call was outgoing) and
(meaning there is no active call),
(meaning the call is
(meaning the call has been discon-
