Setting Bandwidth Thresholds

Bandwidth is a measure of the amount of traffic a switch can handle for receiving, sending,
and on the backplane. The health statistics allow you to sent a percentage of available band-
width, at which an
SNMP
old has been exceeded. To set the threshold levels for switch bandwidth:
1. Enter at a system prompt. The health menu (described above) displays.
2. Enter a at the health menu prompt. The following menu displays:
3. Threshold values are measured as a percentage of the total capacity of the resource. To
change a threshold or sampling interval value, type the index for the field, followed by an
equals sign, then the new value. For example, to change the
percent, you would type the following at the prompt:
The Receive Threshold would now be set to 50 percent of its total capacity (bandwidth).
4. When you have finished entering the new values, you must enter
configuration settings.
Changing a threshold value sets the value for all levels
of the switch (switch, module, and port). You cannot
set different threshold values for each level.
Below is a description of the fields in the
tored resources is eighty (80) percent of the maximum capacity of the resource.
Receive Threshold
The receive threshold sets a percentage of total bandwidth of the switch, module, or port.
When the amount of received data exceeds this percentage, an
Transmit/Receive Threshold
The transmit/receive threshold sets a percentage of the total bandwidth of the switch, module,
or port. When the amount of transmitted and received data exceeds this percentage, an
trap is sent.
trap is generated to alert the network administrator that the thresh-
♦ Note ♦
command menu. The default for all moni-
Setting Resource Thresholds
to 50
to keep the new
trap is sent.
SNMP
