Frame Relay IP Routing
An InARP message is sent between the two routers indicating their IP addresses and associ-
ated VC. Once they know each other's IP address and the
link (the same VC may have a different
ing of RIP frames, etc.

The Frame Relay Subnet and "Split Horizon"

The IP protocol must account for the Frame Relay network in making routing decisions. After
all, the
WAN
routers. The solution is to assign the Frame Relay network a unique IP subnet.
Frame Relay network consid-
ered a unique IP Subnet by IP.
In the configuration shown above, one virtual circuit connects the
1.1.1.x and the other router on IP Subnet 3.3.3.x. The Frame Relay network, for routing
purposes, is considered to be IP Subnet 2.2.2.x. Routing decisions are straightforward in this
setup. But if another Router and another IP Subnet were added, a special routing technique
must be devised.
Page 29-16
network is more than just a single cable, or even several cables, attaching two
Frame Relay Network Is an IP SubNet
of the VC on each end of the
DLCI
on each end), then they can begin normal rout-
DLCIs
Virtual circuit connects
two Routers.
WAN
router on IP Subnet
WSX
