. The number of frames transmitted on this port whose destination
address is the broadcast address.
Note that these statistics merely indicate the format of the destination address of frames trans-
mitted/received on this port, not that the addressed device and/or devices necessarily reside
on that port. For example, unknown unicast addressed frames are flooded to many ports.
. Due to congestion of traffic from multiple ports on the board, timely
access to buffers was not available to receive a frame from the network port and the frame
was discarded.
port, frames received from the backplane destined to this port were dropped.
. Due to congestion of traffic from multiple ports on the board, timely
access to the buffer containing the frame currently being transmitted by this port was not
obtained and the frame had to be aborted and discarded.
. Due to congestion of traffic from multiple ports and boards in the system, traf-
fic received from the network port could not be queued to the backplane due to buffer avail-
ability.
shared segment (e.g., AUI and BNC connected Ethernet) where more than two stations exist.
The first indicates that a frame which the port started to receive from a station was subjected
to a collision from a third station. This is normal. Such collisions between third party stations
may cause this port to see fragments of a frame which are discarded as runts. This too is
normal on multiple station Ethernet segments. On point to point 10Base-T connections these
events may be considered abnormal indicating a possible intermittent wiring problem (unless
hubs which propagate fragments are in use.) These statistics do not indicate the loss of any
frame but rather events associated with the attempts to finally successfully transfer the frame.
. These statistics are all related to collisions and deferral where this port is actively trying
to transmit a frame. The CSMA part of CSMA/CD, the protocol of Ethernet, requires that a
station which wishes to transmit first listens to the media to see if a transmission is already in
progress. If it is, then the station must defer transmission until the media is quiet. The Defer
count is the number of times this happens and is normal. A high defer count, relative to total
numbers of frames transmitted by the port, can be indicative of a busy segment. If a transmis-
sion is not in progress the station may begin to transmit. Due to propagation delays it is
possible for a station to suffer a collision from another station trying to transmit, even though
both listened for quiet media. When this occurs, both stations "back off" for a random time
before attempting transmission again. In theory, subsequent collisions may occur on these
retries. Once, More, and Retry indicate whether this is occurring. If a collision occurs but
succeeds on the retry, the Once counter is incremented, i.e., we collided once. If more than
one retry is required, the More count is incremented. If up to 16 retries are attempted and all
collide, then the frame is dropped and the Retry count is incremented. Again, Once, More,
and Retry are normal events on CSMA/CD media but high numbers, relative to total transmit-
ted frames, are again indicative of a very busy segment whose throughput could be increased
by further segmentation.
. A frame was received with an FCS and/or alignment error. A high
count here, relative to total received frames, is indicative of a noisy media subject to errors.
. This is a count of transmitted frames which are lost due to a loss of carrier.
This is indicative of poor quality/noisy wiring or adapter cards.
. Due to a shortage of buffers and/or congestion on the network
. These counts may be considered normal on a
