Esx-K-100Fm/Fs-16W Technical Specifications - Alcatel Omni Switch/Router User Manual

Fast (100 Mbps) Ethernet Modules
Number of ports
Connector Type
Standards Supported
Data Rate
Maximum Frame Size
MAC Addresses Supported
Connections Supported
Cable Supported
Optical output power
Optical receiver sensitivity
Cable Distance
Current Draw
Page 3-20
ESX-K-100FM/FS-16W Technical Specifications
16
MT-RJ
IEEE 802.3; IAB RFCs 826, 894
100 Mbps (full duplex)
1,518 bytes
8,192
100Base-Fx connection to backbone or server
Multimode: 62.5/125 micron multimode fiber
Single mode: single mode fiber
Multimode: -19 to -14 dBm
Single-mode: -20 to -14 dBm
Multimode: -31 dBm Max.
Single-mode: -31 dBm Max.
Multimode: approximately 2 km
Single-mode: approximately 15 km
9.75 amps without an HRE-X
11.25 amps with an HRE-X
