Alcatel Omni Switch/Router User Manual page 957

Displaying PPP Entity Status
BCP Oper State
Indicates the operational state of the Bridging Control Protocol option. means that the
bridging operation is active. means that the bridging operation has not yet reached the
open state. The reasons why the state may be closed are: 1) the call has been disconnected,
2) the protocol is in the process of making a connection, or 3) the Bridging option was not
configured.
CCP Oper State
The operational state of the compression control protocol option. means that
compression is active. means that compression has not reached the open state. The
reasons why the state may be closed are: 1) the call has been disconnected, 2) the protocol is
in the process of making a connection, or 3) the compression option was not configured.
Displaying the Status of a Specific PPP Entity
To view both the operational status and the relevant statistics of a specific PPP Entity, for
example, Peer ID 1, enter the following command:
A screen similar to the following displays:
The additional fields produced by the command when a specific Peer ID is entered
with the command are as follows:
LCP Pkts IN/OUT
The total number of Link Control Protocol (LCP) packets received ( ) and transmitted ( )
on this PPP connection.
Page 30-19
