Alcatel Omni Switch/Router User Manual page 91

. This label indicates
that the module contains an optical
transceiver).
Each LED corresponds to a port on
the module. When an LED is on
Green continuously, a good cable
connection exists. The LED will
blink Green when traffic is trans-
mitted or received on the port.
MT-RJ connectors will be color
coded to indicate multimode
(Black) or single mode (Blue).
16-Port Advanced Fast Ethernet Switching Module
Fast (100 Mbps) Ethernet Modules
. This label will indicate
the ESX-100FM/FS-16W type. It will
read either (
multimode
) or (single mode
cable
cable).
( H a r d w a r e S t a t u s ) . O n
Green when the module has
passed diagnostic tests success-
fully. On Red when the hardware
has failed diagnostics.
(Software Status). Blinking
Green when the module soft-
ware was downloaded success-
f u l l y a n d t h e m o d u l e i s
communicating with the
MPX
Blinking Red when the module is
in a transitional state. On solid
R e d i f t h e m o d u l e f a i l e d t o
download software from the
.
MPX
Page 3-21
.
