Viewing PPP Entity Configurations
Routing Group
Indicates the VLAN Group to be used for PPP Routing of the IP and IPX protocols. A value of
zero ( ) indicates that this PPP Entity will not perform a routing service and will discard all
routed format packets received or transmitted.
Displaying the Configuration of a Specific PPP Entity
To view configuration information on a specific PPP Entity, you must enter a Peer ID number
with the command. For example, to examine Peer ID 1, you would enter the
following command:
A screen similar to the following displays:
The fields on this screen are similar to those produced by the command. A few
differences are noted in the descriptions that are given below. Note that you cannot make
changes to the parameters on this screen. To do so, you must use the command
instead (see Modifying a PPP Entity on page 30-15 for complete information).
Page 30-17
