If the interface was using PPP, the following screen would display:
The DTR Pulse settings do not apply to T1 and E1
interfaces, and are not described below.
Admin Status
The options for the Admin Status are
and can transmit data as long as its Operational Status is also enabled. If set to
port will not pass data, even if its physical connection is good.
Speed in BPS
This field shows the speed for the T1/E1 port. This field is for reference only.
Clocking
This field shows the type of clocking set for the T1 port. This field is for reference only.
Protocol Type
The protocol type can be set to either Frame Relay or Point to Point Protocol (PPP).
A port must be set to either Frame Relay or PPP before
any other protocol-related parameters can be set.
o Note o
and . If
o Important Note o
The WAN Port Software Menu
, the port has been enabled
, the
Page 28-25
