Rear Panel - Micromeritics TriStar II 3020 Operator's Manual

TriStar II 3020

Rear Panel

Maximum
Helium inlet valve
inlet
pressure
Component
Gas inlet valves
Vacuum pump
connector
On/Off switch
Power cord connector For connecting the analyzer to the power supply.
302-42828-01 - Dec 2012
Analysis inlet valves
Vacuum pump connector
On/Off switch
Power cord
connector
• Analysis - inlets V8, V9 and V14 are for analysis gases.
• He - inlet V7 is dedicated to helium.
For attaching the vacuum pump hose.
For turning the analyzer on and off.
Instrument Components and Connectors
Description
2-3
