7 LIST OF TOOLS

7.1

Tools

No.
1 Correx gauge (Dial tension gauge) 500 gf
2 Correx gauge (Dial tension gauge) 300 gf
3 Correx gauge (Dial tension gauge) 50 gf
4 Cutter plunger
5 Cutter blade
6 Fiber tip pen
7 Push-pull gauge 5 kg
8 Push-pull gauge 2 kg
9 Push-pull gauge 1 kg
10 Scale (300 mm)
11 Windows PC
12 USB I/F cable
13 Phillips screwdriver #1
14 Phillips screwdriver #2
15 Phillips screwdriver #3
16 Flat-head screwdriver #1
17 Flat-head screwdriver #2
18 Hexagon wrench 0.89 mm span
19 Hexagon wrench 1.5 mm span
20 Hexagon wrench 2.0 mm span
21 Hexagon wrench 2.5 mm span
22 Hexagon wrench 3.0 mm span
23 Hexagon wrench 3.5 mm span
24 Box wrench 5.5 mm span
25 Double-sided tape (10 mm wide)
26 Ethyl alcohol
27 Silicon grease (Shinetsu Silicon grease G-501)
FCX2000-UM-251-9730
Tool Adjustment Item
Pen force adjustment
Pen force and belt tension adjustment
Pen force adjustment
Pen force adjustment
Pen force adjustment
Distance adjustment
Belt tension adjustment
Belt tension adjustment
Belt tension adjustment
Distance adjustment
Firmware update
Firmware update
M2,M2.6
M3,M4,M5
M6,M8
For M2 set-screws
For M3 set-screws
For M4 set-screws
For M3 socket-screw
For M4 socket-screw
For M5 socket-screw
For removing M3 nuts
For securing the FPC cables
For cleaning the electrostatic adhesion plate and rail
Belt
