9 ELECTRICAL ADJUSTMENTS
9.2

Flowchart of the Adjustment Sequence

Flowchart of the Adjustment Sequence for the FCX2000 series.
9.2.1

The main board was replaced (Normal procedure)

When the main board was exchanged, copy adjustment values to the main board from the SUB-NVRAM by
the following procedure.
9.7 Clearing the Non-Volatile RAM for corresponding model
9.5 Set the dip switch for corresponding model
9.6 Updating the System Firmware
9.9 Remove the SUB-NVRAM from previous main board
9.9 Install the SUB-NVRAM to the new main board
9.9 Copy the adjustment values from the SUB-NVRAM to main board
End of Main Board replacement
FCX2000-UM-251-9370 9-2
