8
DISASSEMBLY AND ASSEMBLY
(6) Adjust the Y bar angle to be parallel from the left edge of honeycomb plate.
The left side edge of honeycomb plate
Left edge of Y bar
(7) Tighten the four M4L5 set screws holding the rear X drive pulley.
FCX2000-UM-251-9370
8-23
