9.5

Setting the DIP Switches

Settings for the DIP Switch on the Main Board
DIP Switch Factory Settings (Normal mode)
This setting depends on the model.
Dip Switch
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
Note:
The NV-RAM CLEAR must perform when the dip switch setting was changed from previous settings.
NV-RAM CLEAR Function mode
All adjustment values are cleared to the default value of each model when the NV-RAM CLEAR was
performed.
Dip Switch
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
Emergency Mode
The plotter will not detect the X and Y home position at this mode.
The plotter can use temporary when the X or Y home sensor was broken.
The pen block must move to the home position manually when turn on the power for the plotter in this mode.
Dip Switch
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
FCX2000-UM-251-9370
1 2 3
ON
OFF OFF OFF OFF OFF OFF OFF OFF FCX2000-60
OFF
ON
ON OFF OFF OFF OFF OFF OFF OFF FCX2000-120
OFF
ON
OFF ON OFF OFF OFF OFF OFF OFF FCX2000-180
OFF
1 2 3
ON
OFF OFF OFF ON OFF OFF OFF OFF FCX2000-60
OFF
ON
ON OFF OFF ON OFF OFF OFF OFF FCX2000-120
OFF
ON
OFF ON OFF ON OFF OFF OFF OFF FCX2000-180
OFF
1 2 3
ON
OFF OFF OFF OFF OFF OFF OFF OFF FCX2000-60
OFF
ON
ON OFF OFF OFF OFF OFF OFF OFF FCX2000-120
OFF
ON
OFF ON OFF OFF OFF OFF OFF OFF FCX2000-180
OFF
9 ELECTRICAL ADJUSTMENTS
4 5 6 7
4 5 6 7
4 5 6 7
9-8
8 Model
8 Model
8 Model
