2 Setup Procedure

2.1

Installation Space

Please secure a space for installation as according to the below illustration.
Leave sufficient space for operations in front of and behind the plotter.
600 mm
FCX2000-UM-251-9370
100 mm
500 mm
2-1
2
Setup procedure
600 mm
