8.1.5
Right Top Cover
How to detach the Right Top Cover
(1) Remove the four M4L8 binding head screws holding the right top cover, and then detach it.
How to reinstall the Right Top Cover
(1) Reattach the right top cover in the reverse order in which it was detached.
8.1.6
Left Top Cover
How to detach the Left Top Cover
(1) Remove the four M4L8 binding head screws holding the left top cover, and then detach it.
How to reinstall the Left Top Cover
(1) Reattach the left top cover in the reverse order in which it was detached.
FCX2000-UM-251-9370
Right top cover
M4L8 binding head screw
Left top cover
8-3
8
DISASSEMBLY AND ASSEMBLY
M4L8 binding head screw
