10.8 Operational Error

Error cord No.
E05001
E05002
E05003
E05006
E05007
E05008
E05009
E05010
E05011
E05012
E05013
FCX2000-UM-251-9370
LCD Display
Data larger than the
buffer size cannot be
copied.
There is no data to copy. Perform normal cutting by
Media valid area to copy
is too small.
Distance between the
bottom left and top right
of the AREA setting is
less than 10 mm.
Test pattern for the TOOL
OFFSET ADJ. cannot
start plotting because
the start position is at the
edge of the media.
The external memory
(USB memory) is not
recognized.
The bar code is not
detected.
When the ROTATION is
enabled, the bar code
cutting function is not
available.
When the REVERSE
CUTTING is enabled,
the bar code cutting
function is not available.
The appropriate file
cannot be found in the
external memory (USB
memory).
The START MARK is not
recognized.
10-19
10 TROUBLESHOOTING
Cause
It can not use the copy mode.
sending the data, then use
the copy mode.
Use larger media.
Confirm the copy start
position.
Perform the AREA setting
again.
Set the start position inside
the media.
Insert the external memory
(USB memory).
Check at the printing state of
bar code and set the proper
bar code settings.
Set the ROTATION to
Disabled to use this bar code
cutting function.
Set the REVERSE CUTTING
to Disabled to use this bar
code cutting function.
Save the appropriate file in
the external memory (USB
memory).
Confirm the printing state of
bar code.
Move the tool carriage to the
START MARK.
Solution
