11.3 Control Box

No. Part No.
1 U792200700 Main Board, FCX2000
2 U694600620 USB Cable, CBL0106ACL2-1.1M
3 U682259170 Fan, TUDC24B4-602
4 U682260310 Power Supply Unit, LFP150F-48-D40.5
5 U361102002
6 U622620520 USB Cable Bracket
7 U561550277 AC Inlet, AC-P10CF34
8 U792220760 USB Relay Board, FCX2000
9 U682260320 Power Switch, AJ8R2011BBCF
10 U692260105 Cable, CA403110E
U622620512 Control Box Chassis
11
U622629501 PL-Control Box Chassis
12 U361102022
13 U395030100 Spacer, ASB-310E
14 U363013061 Rubber Foot, TM166-18
Control Box
10
11
FCX2000-UM-251-9370
Description
Cable Clamp, EDS-1
Cable Clamp, RSPC-335P
1
13
14
Q'ty
1
1
1
1
2
1
1
1
1
1 For Warning Light Model
1
For Warning Light Model
3
12
2
2
3
12
14
11-5
11. PARTS LIST
Remarks Rank
C
D
D
D
C
C
D
D
D
C
4
5
6
5
7
8
9
A
A
A
A
