DISASSEMBLY AND ASSEMBLY
(7) Detach the rear bottom cover as shown in the picture below.
(8) Detach the X flexible cable from the rear bottom cover.
How to reinstall the Rear Bottom Cover
(1) Reattach the rear bottom cover in the reverse order in which it was detached.
FCX2000-UM-251-9370
