9 ELECTRICAL ADJUSTMENTS
9.2.2 The main board was replaced
(If the adjustment values could not copy from the SUB-NVRAM.)
When the main board was exchanged, if the adjustment values could not copy from the SUB-NVRAM to the
main board, perform the following procedure.
9.7 Clearing the Non-Volatile RAM for corresponding model
9.5 Set the dip switch for corresponding model
9.6 Updating the System Firmware
9.10 Adjusting the Home Position
9.11 Adjusting the Pen Force
9.12 Adjusting the Distance and the Perpendicularity Accuracy
9.13 Adjusting the Tool Interval
9.14 Adjusting the Registration Mark Sensor Sensitivity
9.15 Adjusting the Offset of Registration Mark Sensor
9.16 Back up to the SUB-NVRAM
End of Main Board replacement
