GRAPHTEC FCX2000 Service Manual page 205

Error cord No.
E01019
E01021
FCX2000-UM-251-9370
LCD Display
The pen block hits
something and then
stops when it is moving.
The Y home sensor is
defective.
The home position was
not set to the correct
position after the main
board was replaced.
The Y motor is defective. Replace the Y motor if the pen
The main board is
defective.
The pen block or the Y
bar hits something and
then stops when it is
moving.
10-17
10 TROUBLESHOOTING
Cause
Remove the object disturbing
the operation, and then turn
on the power after turning off
the power.
Replace the Y home sensor
when the pen block moves
+Y direction slowly and the Y
position error is displayed.
Set the correct home position
when the Y position error is
displayed after the pen block
moved to the bottom end or
top end.
block moves quickly when it is
cutting the Y direction.
Replace the main board
when the Y position error is
displayed without moving the
pen block.
Remove the object disturbing
the operation, and then turn
on the power after turning off
the power.
Solution
