11.4 Control Panel

No. Part No.
1 U622624290 Control Panel Sheet
2 U622624202 Control Panel Cover
3 U622624230 Right Key Top
4 U622624220 Cursor Key Top
5 U622624240 Function Key Top
6 U792200710 Control Panel Board, FCX2000
7 U682157130 LCD, BTG240128SFBWBGG
8 U622624211
Control Panel
FCX2000-UM-251-9370
Description
Control Panel Bottom Case
5
7
Q'ty
1 OPE_SHEET
1 CONT_PANEL
1 RIGHT_KEY
1 CUR_KEY
1 FUNC_KEY
1
1
1
1
2
3
4
6
8
11-6
11. PARTS LIST
Remarks Rank
C
C
C
C
C
C
A
A
