GRAPHTEC FCX2000 Service Manual page 252

13 Target electrical component for WEEE instruction
(5) Detach the main board from the control box.
(6) Disconnect all the cable from the power supply board.
(7) Remove the four M3L6 binding head screws holding the power supply board.
Power supply board
M3L6 binding head screw
(8) Detach the power supply board.
(9) Remove the four M3L6 binding head screws holding the control box.
M3L6 binding head screw
Control box Control box
M3L6 binding head screw
FCX2000-UM-251-9370 13-5
