(7) Operate switches and sensors following the instructions on the screen.
"OK" will be displayed if the operation is detected correctly, and next test will start.
It will return to TEST menu screen once all the test items are completed.
Test items are as following.
1 X Home sensor
5 Tool 1 height signal
9 [3]key
13 POSITION[▲]key
17 [PAUSE/MENU]key 18 [COND/TEST]key
21 [ESC]key
FCX2000-UM-251-9370
2 Y Home sensor
6 Tool 2 height signal
10 [4]key
14 POSITION[ ]key
22 [ENTER]key
10-22
3 X motor signal
7 [1]key
11 [USER1/2]key
15 POSITION[▼]key
19 [ORIGIN]key
10 TROUBLESHOOTING
4 Y motor signal
8 [2]key
12 [SLOW]key
16 POSITION[ ]key
20 [COPY]key
