11.6 Y Bar Part

No. Part No.
1 U682260270 Y Motor, UGFMED-C9SB4OERX
2 U622622400 Pulley, Motor, S2M24Z-PULLEY-ASSY
3 U311069820
4 U622622422 Gear, S2M72Z
5 U622622001 Motor Bracket, MOTOR-BRA
6 U622622430 Gear Shaft, SCM-Z35M05
7 U378009591 Belt, 120S2M190G
8 U692260114
9 U792220720 Y Relay Board, FCX2000
10 U692260314 Y Flexible Cable, FFC403101D
11 U622623901 Y Gear Box, Y-FINAL-BOX
12 U621582090 Bearing, 6900ZZNXRJECE
13 U622623872 Top Gear Box Cover
14 U622623051 Bracket, Y Cable Bracket
15 U361104005
16 U622623880 Bottom Gear Box Cover
17 U622623862 Y Drive Shaft
18 U622623853 Gear, Y-M05Z126
19 U310680021 Bearing, 6900ZZCMR NS7S
20 U622623910 Collar, CENTER-COLLAR
21 U622623841 Y Belt Drive Pulley, S3M36Z-Y-PULY
22 U622623051 Bracket, Y Home Sensor Cable
23 U622623802 Y Bar End Plate, Y-END-PLT-ASSY
24 U622623282 Y Stopper Rubber, Y_SLID_CUSHION
U792260341 X Flexible Cable 60, FFC403104A
25 U792260323 X Flexible Cable 120, FFC403102C
U792260333 X Flexible Cable 180, FFC403103C
26 U622622202 Bracket, X Flexible Cable
27 U622623062 Y Bar Rear End Angle
28 U621583390 Roller B, R1240KK1MTRP5
29 U395233030 Spacer, CU-303
30 U392230020 Spacer, CU-302
31 U622623161 Wiper, X Y-SIDE-WIPER-A
32 U622623171 Wiper, X Y-SIDE-WIPER-B
33 U622623151 Slider Roller Tension Plate
34 U622623190 Slider Fix Plate
35 U792220780 Pen Relay Board, FCX2000
36
37 U622623112
38 U622623103 Y Slider, FCX2000
39 U622623271 Y Belt Stopper Plate
40 U309001006 Bush, C4L3
41 U622623180 Y Baring Shaft
42 U622623710 Y Belt, 300S3M816LWC
43 U792220730 Home Sensor Board, FCX2000
44 U361102021
45 U622623642 Shaft, Y Tension Shaft
46
47 U313600020 Bearing, 6000ZZNRAV2
48 U622623680 Tension Pulley, 26NR-PULLEY
49 U622623622 Bracket, Y Tension Arm
50 U622623650 Plate, Y Tension Plate
51
52 U622623093 XY Joint Bracket
53 U622623612 Bracket, Y Tension Base
54 U622623604 Y Side Plate R
55 U622623292 Bracket, Y Slider Stopper
56 U622623000 Y Bar, FCX2000
57 U622623011
58 U305301033 Square Plate Nut, M3
59 U622623030 Y-RAIL-NUT
FCX2000-UM-251-9370
Description
Bearing, F698ZZ1MC3PS2S
Cable, CA403111D, Y Home Sensor
Edge Saddle, ES-0505-2
Core,
Y Home Sensor Dog
Cable Clamp, RSPC-115S
Bush, C10L9.5
Bush, C10L9.0
Plate, Liner, FCX2000
Q'ty
1 UGFMED-C9SB4OER
1
2
1
1
1
1 Motor Belt
1
1
1
1
2
1 FFC-UPPER
1
3
1 FFC-UNDER
1 Y-DRIVE-SHAFT
Y-M05Z126
1
1
1
1 Y-SENS-BRA-R
1
2
For FCX2000-60
1 For FCX2000-120
For FCX2000-180
1 NEW-FFC-BRA
1 Y-NECK-ANGLE
8
2
2
2
2
Y-SLID-FIX-BRA
1 Y-SLID-FIX-SPA
1
1 Y-HOM-D-FCX2-R
1 Y-SLIDER-FCX2
2 BELT_PLAT-FCX2
1
2 Y-BEA-SHAFT
1
1 X,Y Common
1
1 Y-TEN-SHAFT
1
2
1
1 Y-TEN-ARM
1 Y-TEN-PLATE
1
1 XY-JOIN-BKT
1 Y-TEN-BASE
1 Y-SIDE-PLATE-R
1 Y_SLID_STOPER
1 Y-RAIL-FCX2
4 LINER-FCX2
5
2
11-8
11. PARTS LIST
Remarks Rank
C
C
C
D
C
C
C
D
C
D
D
D
D
D
C
C
C
C
D
D
C
D
D
C
D
D
C
C
C
C
C
C
D
C
D
C
D
C
C
C
C
D
C
C
D
D
C
C
D
D
A
A
A
A
A
A
A
A
A
