11.9 Wiring Harness

No. Part No.
1 U692260094 Cable, CA403109D
U792260341 X Flexible Cable 60, FFC403104A
2 U792260323 X Flexible Cable 120, FFC403102C
U792260333 X Flexible Cable 180, FFC403103C
3 U694600620 USB Cable, CBL0106AC2-1.1M
4 U692260035 Cable, CA403103E
5 U692260114
6 U692260314 Y Flexible Cable, FCC403101D
7 U692260073 Cable, X Registration Mark Sensor, CA403107C
8 U692260123 Cable, Y Registration Mark Sensor, CA403112C
9 U692260182 Cable, CA403118B
10 U692260105 Cable, CA403110E
FCX2000-UM-251-9370
Description
Cable, CA403111D
Q'ty
1 Main to Key Board
1 FCX2000-60
1 FCX2000-120
1 FCX2000-180
1 Main to USB Relay Board
1 Main to X Home Sensor B
1 Main to Y Home Sensor B
1
1 Pen relay Board to X regi
1 Pen relay Board to Y regi, 4P
1 Main to HV Board, 120ES only
1 Warning Light OP, Main to WL
