Chapter 1 PRODUCT SUMMARY

1.4 Control Panel

Indicator Lamps
................The POWER lamp remains lit (green) while the plotter is on.
..............The PROMPT lamp lights (red) when the plotter receives data that will cause the pen carriage
(FC4500-50 only)
......................Press the [CHART HOLD] key to enable the electrostatic adhesion function (the key's lamp
Panel Keys
..................[FUNCTION] keys
...........[POSITION] keys
...........................[PAUSE] key
1-4
FORCE
F1
F2
SPEED
POWER
PROMPT
to move outside the effective cutting area or receives the Prompt Light command (T) from the
computer.
lights). Press it again to cancel the electrostatic adhesion function (the lamp goes off).
Depending on the setting screen being displayed, these keys are used to:
•
Load a group of cutting conditions retained in the plotter's memory;
•
Shift the blinking display in a conditions setting screen;
•
Select the desired submenu in a menu screen.
Depending on the plotter's operating status, these keys are used to:
•
Move the tool carriage;
•
Move the blinking display in a conditions setting screen; ([
•
Raise or lower the numeric value of a setting; ([
•
Change the pen type. ([
•
Press the [ ] key and the [ENTER] key concurrently to move the tool carriage to the upper
right position. To move the tool carriage to the origin position, press the [
[ENTER] key concurrently.
Press the [PAUSE] key to select PAUSE mode (its green lamp lights).
Press it again to cancel PAUSE mode (the lamp goes off).
Depending on the plotter's operating status, this key is used to:
•
Temporarily suspend a cutting or plotting operation.
•
Set functions at the control panel.
•
Temporarily store data received from the computer in the plotter's buffer.
OFFSET
QUALITY
] and [
] and [ ] keys)
F3
F4
] and [ ] keys)
] keys)
] key and the
