ST STM32F205 series Reference Manual page 1122

USB on-the-go high-speed (OTG_HS)
Table 163. Device-mode control and status registers (continued)
Acronym
OTG_HS_DIEPEMPMSK
OTG_HS_DEACHINT
OTG_HS_DEACHINTMSK
OTG_HS_DIEPEACHMSK1
OTG_HS_DOEPEACHMSK1
OTG_HS_DIEPCTLx
OTG_HS_DIEPINTx
OTG_HS_DIEPTSIZ0
OTG_HS_DIEPDMAx/
OTG_HS_DOEPDMAx
OTG_HS_DTXFSTSx
OTG_HS_DIEPTSIZx
OTG_HS_DOEPCTL0
OTG_HS_DOEPSIZ0
OTG_HS_DOEPCTLx
1122/1378
Offset
address
OTG_HS device IN endpoint FIFO empty interrupt mask register:
0x834
(OTG_HS_DIEPEMPMSK) on page 1170
OTG_HS device each endpoint interrupt register
0x838
(OTG_HS_DEACHINT) on page 1170
OTG_HS device each endpoint interrupt register mask
0x83C
(OTG_HS_DEACHINTMSK) on page 1171
OTG_HS device each in endpoint-1 interrupt register
0x844
(OTG_HS_DIEPEACHMSK1) on page 1171
OTG_HS device each OUT endpoint-1 interrupt register
0x884
(OTG_HS_DOEPEACHMSK1) on page 1172
0x900
0x920
OTG device endpoint-x control register (OTG_HS_DIEPCTLx) (x =
0..7, where x = Endpoint_number) on page 1173
...
0x9C0
OTG_HS device endpoint-x interrupt register
0x908 (OTG_HS_DIEPINTx) (x = 0..7, where x = Endpoint_number) on
page 1180
OTG_HS device IN endpoint 0 transfer size register
0x910
(OTG_HS_DIEPTSIZ0) on page 1183
OTG_HS device endpoint-x DMA address register
0x914/0xB14 (OTG_HS_DIEPDMAx / OTG_HS_DOEPDMAx) (x = 1..5, where
x = Endpoint_number) on page 1187
OTG_HS device IN endpoint transmit FIFO status register
0x918 (OTG_HS_DTXFSTSx) (x = 0..5, where x = Endpoint_number) on
page 1186
0x930
OTG_HS device endpoint-x transfer size register
0x950
(OTG_HS_DOEPTSIZx) (x = 1..5, where x = Endpoint_number)
...
on page 1186
0x9D0
OTG_HS device control OUT endpoint 0 control register
0xB00
(OTG_HS_DOEPCTL0) on page 1176
OTG_HS device OUT endpoint 0 transfer size register
0xB10
(OTG_HS_DOEPTSIZ0) on page 1184
0xB20
0xB40
OTG device endpoint-x control register (OTG_HS_DIEPCTLx) (x =
0..7, where x = Endpoint_number) on page 1173
...
0xBC0
RM0033 Rev 8
Register name
RM0033
