RM0033
Mode C - NOR Flash - OE toggling
The differences compared with mode1 are the toggling of NOE and the independent read
and write timings.
Figure 406. Mode C read accesses
A[25:0]
NADV
NEx
NOE
NWE
High
D[15:0]
Figure 407. Mode C write accesses
A[25:0]
NADV
NEx
NOE
NWE
D[15:0]
HCLK cycles
RM0033 Rev 8
Flexible static memory controller (FSMC)
Memory transaction
ADDSET
HCLK cycles
Memory transaction
data driven by FSMC
ADDSET
data driven
by memory
DATAST
HCLK cycles
1HCLK
(DATAST + 1)
HCLK cycles
ai15564
ai15565
1277/1378
