Table 196. Fsmc_Btrx Bit Fields - ST STM32F205 series Reference Manual

RM0033
Bit No.
3-2
1
0
Bit No.
31:30
29:28
27-24
23-20
19-16
15-8
7-4
3-0
Table 195. FSMC_BCRx bit fields (continued)
Bit name
MTYP[0:1] 0x1 or 0x2
MUXEN As needed
MBKEN 0x1

Table 196. FSMC_BTRx bit fields

Bit name
Reserved 0x0
ACCMOD 0x0
DATLAT Data latency
0x0 to get CLK = HCLK (not supported)
CLKDIV 0x1 to get CLK = 2 × HCLK
..
BUSTURN Time between NEx high to NEx low (BUSTURN HCLK)
DATAST Don't care
ADDHLD Don't care
ADDSET[3:0] Don't care
