Flexible static memory controller (FSMC)
Muxed mode - multiplexed asynchronous access to NOR Flash memory
The difference with mode D is the drive of the lower address byte(s) on the databus.
1282/1378

Figure 410. Multiplexed read accesses

Figure 411. Multiplexed write accesses

A[25:16]
NADV
NEx
NOE
NWE
AD[15:0]
ADDSET
HCLK cycles
Memory transaction
Lower address
ADDHLD
HCLK cycles
RM0033 Rev 8
1HCLK
data driven by FSMC
(DATAST + 1)
HCLK cycles
RM0033
ai15569
