430 A B: D
PPENDIX OWNLOADING
Hardware and
Software
Requirements
Connecting to the
Control Port
RS-232 Upgrade
Instructions
Putting the Standby
Switch Fabric Module
into Suspend Mode
S
OFTWARE
CAUTION: Make sure that the CoreBuilder 9000 ATM Enterprise Switch
is properly grounded before you begin.
The following items are required for loading the software:


PC 486 or higher, running MS-Windows 3.1 or higher with
MS-Terminal emulator software such as PCPlus.


RS-232 port and cable


3Com's CoreBuilder 9000 current software release
Set your PC terminal emulation to the following parameters:


8 data bit


1 stop bit


no parity


no XON/XOFF


9600 Baud


Binary transfer set to Xmodem/CRC. (that is, Setting > binary transfer
> Xmodem/CRC)
Connect your PC to the RS-232 Control Port of the ATM Switch Fabric
Module.
If you have two Switch Fabric Modules installed in your CoreBuilder 9000
chassis, you must put the standby Switch Fabric Module into Suspend
Mode using the following procedure:
1 Enter the LMA command 1 4 3 2 at the main menu prompt. The
following prompt is displayed:
Put standby switch to suspend mode?
2 Enter y.
