Display VPI/VCI
Range
V C
IRTUAL HANNELS
Display the current signaling protocol VPI/VCI configuration parameters
for a specified port. Maximum and minimum VPI/VCI values are displayed
for each port.
These parameters are set to match the VPI/VCI capabilities of the device
attached to the specified port. If an end station or edge device is attached
to the port, it frequently has limits on the VPI/VCI channels it can handle;
you must set the CoreBuilder 9000 ATM Enterprise Switch port to match
these limits.
You can set these parameters independently for each port.
Command Actions
Enter the menu sequence:
Enter a parameter at the prompt
Parameter
Port number
Direct access sequence:
Command Result
System action taken:
System message display:
(1) SYS: Platform Configuration
(1) SET: Switch Setup
(4) SIG: Signaling Setup
(3) VCC: VPI/VCI range setup
(1) GET: Get VPI/VCI range
Format or Range
<slot.group.port> or 0.0 for all ports
1 1 4 3 1 [parameters]
The current VPI/VCI Configuration Parameters for the
specified port are displayed.
Information is displayed as shown in the example.
